35 FEET PMW
Efficient, Stealthy and Proven High Speed Craft

Extreme Endurance and High Speed
Minimal Signature
Proven Hull

Overview

Swift 35 Feet PMW is built on Swiftships’ 80+ years of experience providing robust, reliable small craft for near-shore and riverine operations in austere environments.  PMW is a USMC proven platform, built to operate in tropical regions with assured top performance in sustained ambient air temperatures over 100° Fahrenheit.

The PMW platform is designed to conduct littoral / distributed operations and is capable of performing reconnaissance, sensing, tactical maneuver, and logistics support in the maritime domain, in both international deep blue waters and coastal/riverine zones. The PMW is a revolutionary platform due to its extreme endurance, speed, minimal signature, ability to support manned/unmanned assets (+100-200 nodes via 5G.MIL® Lockheed’s Martin), and affordability.



Key Features

45+ Knots
with range of 410nm
Shallow Waters and High Seas
with performance in open water up to Sea State 2, with survivability up to Sea State 4
520 NM Range
@35+ knots and 15 hours endurance
5G Situational Awareness
5G.MIL® Lockheed's Martin solution to enable JADC2 and JADO
Low Observability
limited signature for reduced radar cross-section detection
Cost Effective
low maintenance and easiness to transport

Efficient, Stealthy and Proven

Technical Specification

LENGHT

35 Feet (10.67 Meter)

BEAM

8.1 Feet (2.47 Meter)

DRAFT

1.7 Feet (0.52 Meter)

SPEED

45+ knots

FUEL CAPACITY

450 Gallons (1703 Liters)

RANGE
  •  @ 35 knots – 520 NM
    [Endurance 15 hours]
  • @ 45 knots – 410 NM
    [Endurance 9 hours]
DISPLACEMENT

16,000 lbs.

CREW

4 Crew (plus 15 Troops)

MACHINERY
  • Engines: Two (2) Fiat (FPT 67-550)
    @ 480MHP 3200 RPM
  • Propulsion: Two (2) Hamilton WJ
    (Model HJX27) @ 353 kW and
    2990 rpm
SYSTEMS
  • Electronics – Furuno NAVNET system
    (chart plotter/radar/fathometer/GPS)
  • FLIR EO/IR night vision camera
    system (optional)
  • 5G situational awareness
    communication system –
    Lockheed Martin (optional)
  • Autonomous integration – L3H
    (optional)
  • Magnetic compass – Ritchie
  • Communications:
    – VHF/SSB (optional)
    – Tactical radios and Satellite
    communications (optional)
ARMAMENT & WEAPONS
  • Twin 50 Cal [M2HB] machine gun
    w/revolving tubs (Fwd & Aft)
  • 6 x AR 15/AR 10 mounts (3 port/3 stbd)
    crew served weapons
  • One (1) 40mm MK-19 grenade launcher
  • Ballistic protection NIJ level 3
  • CROWS weapon system
  • HERO 120 UAV strike system
